D1200-3 Series Aluminum Multi Section Extension Ladders

Compact Design
16 foot ladder reduces to 6 feet which makes it easy to maneuver through tight spaces.
Carry Handle
Lightweight aluminum design with a convenient handle makes it easy to carry from storage to project.
Easy to Transport and Store
Compact design makes it easy to transport and store in small spaces.
Use Indoors and Outdoors
Designed to move from room to room and when fully extended reach up to 15 feet for hard to reach outdoor projects.

D1200-3 Series Overview

The D1200-3 series aluminum extension ladders are Compact 3 section ladders that have a duty rating of 225 pounds and interlocking side rails. The Traction-Tred D rungs are slip resistant. Spring-loaded locks operate smoothly for easy operation. Shoes rest flat or are held in spur position with Shu-Lok feature. Mar-resistant end caps help protect the surface ladder is leaning against. Exclusive Alflo rung joint means Twist-Proof performance every time.

Series Performance Overview

SizeReach HeightLoad CapacityTypePerformance RatingMaterial
16'15'225 lbs.Type II Duty RatingAluminum

Series Dimensions Overview

Rails DimensionFlange DimensionRung DimensionFly WidthBase Width
3"1"1-3/4"15-1/4"17-3/8" outside rails

Series Model Matrix

Model No. Buy Online
D1216-3
Different types of ladders are designed to keep you safe and productive when climbing or standing. Using the wrong style of ladder or simply ignoring the limitations of climbing equipment can result in a fall or serious injury.
Height is referring to the actual ladder height. Extension ladders should be 7 to 10 feet longer than the highest support or contact point, which may be the wall or roof line. The highest standing level is four rungs down from the top. The highest permitted standing level on a stepladder is two steps down from the top.

Reach height is the maximum reach assuming a 5’6” person with a vertical 12” reach.
Ladders are designed to safely hold up to a specific amount of weight. The Werner Performance System defines five different capacities using a color and star rating system . The Duty Rating is defined as the maximum safe load capacity of the ladder. A person’s fully clothed weight plus the weight of any tools and materials that are carried onto the ladder must be less than the load capacity. (include image – you can keep the existing image but add the weights like on the ladder finder)
Werner offers ladder made from fiberglass and aluminum. Each material has characteristics which make it best for certain applications, or one material may simply fit the personal preferences of the user. For example, if working around electricity users should select fiberglass products due to their non-conductive side rails.
